Serial communication
| Number of serial ports | 1port9pinDsub, 1port3pinScrew |
| Serial port 1 | RS 232 (RTS/CTS) |
| Serial port 2 | RS422/485 |
| Serial port 3 | RS 485 |
| Serial port 6 | RS 485 |
Mechanical
| Mechanical size | 290 x 193 x 40mm |
| Panel Mount | |
| 1million finger touch operations | |
| Touch type | Resistive |
| Cut-out size | 275 x 177mm |
| Weight | 0.86 kg |
| Housing material | Plastic (PC+ABS), Gray |
| Buzzer | No |
| LED | No |
Power
| Input voltage | 24 V DC (18 to 32 VDC) CE: The power supply has to be conform with the requirements according to IEC 60950 and IEC 61558-2-4.UL and cUL: The power supply has to be conform with the requirements for class II power supplies. |
| Power consumption (max) | 6.9 W |
| Input fuse | Internal DC fuse |
| CPU | ARM Cortex A8 600MHz |
| RAM | 512 MB |
| FLASH | 2 GB |
Display
| Size diagonal | 10.1″ diagonal |
| Resolution | 1024 × 600 pixel (17:10) |
| Backlight | LED Backlight |
| Backlight life time | 30000 hours |
| Backlight brightness | 350 cd/m² |
| Backlight dimming | Industrial Dimming |
| Display type | TFT-LCD with LED backlight |
